Gearmotor VarmoTech FBT3 S85 M32 3.0E

SKU:

AC gearmotor 3.0 RPM with encoder and 8.5 mm shaft clockwise rotation.
Save 0.00 € (- 0 %)

192,60 € 192,60 € 192.6 EUR

157,87 €

    This combination does not exist.


    Temporary Suspended Discontinued

    Designed for low speed and high torque applications. FB1285 - DV3029 geared motor is suited to be used as rotor in pellet stoves.

    For stoves:

    • CLAM Cod. 05023012 - 05010034 Mod. Niagara - Vittoria 26 kW

    Equivalent to Kenta cod. 14702060

    Technical data

    General data
    Rotation speed3,00 RPM
    Magnetic core32 mm
    Shaft diameter8,50 mm
    Shaft millingSingle
    RotationClockwise
    Output torque26 Nm
    Encoder
    Power supply
    Power consumption25 W
    Power supply230/1/50 V/Ø/Hz
    Physical Dimensions
    Dimensions (L x W x H) 0.0 x 0.0 x 0.0 mm
    Net Weight 1.8 kg
